SBS-7600 2-K Nano-Ceramic Coating by Smarter Building Systems LLC

SBS-7600 is an advanced 2-K Nano-Ceramic Long Life Color Coating known for its remarkable UV resistance and durability, making it an ideal choice for industrial applications. Here are the key features and application details:


UV Resistant and Durable

SBS-7600 offers exceptional UV resistance and creates a hard, long-lasting finish, making it well-suited for industrial use.


Self-Priming

This coating is self-priming on most substrates, reducing the time and labor required for application. It is suitable for a wide range of applications, including above-water line marine use, architectural projects, industrial applications, agricultural structures, and heavy-service land-based or offshore structures and equipment.


Color Options

SBS-7600 is available in a variety of standard colors, and custom colors can be accommodated.


Compatibility with SBS-520 Primer

It can be used with SBS-520 primer to improve adhesive bonding, especially on challenging-to-bond materials or surfaces contaminated with silicone.

Application Methods

  • SBS-7600 can be applied using spray, roller, or brush methods.

  • Components A and B should be power-mixed to achieve a uniform consistency.

  • Due to flammability, appropriate mixing equipment and ventilation are required. Refer to the product Safety Data Sheet (SDS) before use.

Automobile Painting
service-worker-painting-car-auto-service (1).jpg
Surface Preparation:
For Metal or Non-Ferrous Surfaces:

  • Ideally, start with a clean and dry surface. Abrasive blasting (white blast) is preferred for metal surfaces, followed by immediate coating to prevent flash-rusting.

  • If abrasive blasting is not possible, mechanical methods or a hand descaling brush can be used to remove loose rust scale or flaking paint.

For Gelcoat or Composite Surfaces:

  • Clean the surface thoroughly with a suitable cleaning solution or sand it to create a prepared surface. Ensure the removal of oils, dust, or other foreign matter.

  • SBS-7600 can also be top-coated with SBS-40 nano-ceramic clear coat for added protection.

Spray Equipment:

  • Always test the application technique on a sacrificial substrate before using it on the final part.

  • Recommended spray nozzle orifice: 1.5 to 2.0mm.

  • Recommended nozzle pressure: 0.3 to 0.4 MPa or 58psi.

  • It is advised to apply the coating with a tack coat followed by the typical box coat method for uniform thickness.

  • For spray application, apply with 50% overlapping passes to ensure an even coating.

  • Clean tools with MEK or a similar solvent.

SBS-7600 2-K Properties:

  • Color: Refer to the 7600-color chart

  • Viscosity: >0.21 cm2/s (104°F/4)

  • Percent of Solids Mixed (90-91%): Part A Resin 96%, Part B Hardener 71%

  • Mix Ratio: 4:1 (80:20)

  • Odor – Liquid: Slight Solvent

  • Odor – Cured: None

  • NFPA Flame Spread: Class A

  • V.O.C. (Compliant): 0.9 per/US Gal

  • Adhesion: 5B (ASTM D3359-02)

  • Mass Density: 11.3 lb/US Gal

  • Recommended DFT: 3.0 – 7.0 per coat

  • Theoretical coverage rate: 289 FT2/US Gal for 5.0 mils

  • Pot life (@ 65-70°F): 4 hr.

  • Dry to the touch (@ 65-70°F): 1.5-2 hr.

  • Recoat time (@ 65-70°F): 1.5-2 hr. minimum.

  • Cure time (@ 65-70°F): 4-4.5 hr.

  • Force dry (after dry to the touch): 140°F max

  • Salt Spray (5% solution): 5500 Hours

  • UV resistance: Excellent

  • Application temperature: 5° above dew point

  • Relative humidity during application & cure: at 40% minimum


For surfaces with questionable conditions or contamination, consider using the SBS-520 nano-ceramic adhesion primer.

Please note that the suitability of this product for specific applications is the responsibility of the end user, and no specific warranty or R-value claims are made by the manufacturer.
