SBS-Thirty-Plus Insulation Coating by Smarter Building Systems LLC
SBS-Thirty-Plus is an extraordinary insulation, corrosion protection, and moisture-resistant coating offering unmatched performance. Key features and benefits include:
Epoxy Ceramic Base
SBS-Thirty-Plus is an epoxy ceramic-based coating renowned for its resistance to heat and water, delivering exceptional insulation properties. Even at a mere 10 mils (0.25 mm) thickness, it boasts a low K-value of 0.02 WMK, making it a true insulation solution.
Versatile Insulation
Unlike mere reflectors, SBS-Thirty-Plus provides genuine insulation and retains this capability even if it becomes dirty or loses its reflectivity, thanks to its unique components. Furthermore, it offers up to 68% sound reduction, as confirmed by independent tests.
Robust Water Resistance
SBS-Thirty-Plus can be applied underwater, even in saltwater conditions, without losing its effectiveness. It can remain submerged indefinitely with no harm to the coating, and it safeguards against damage from standing water.
Broad Substrate Compatibility
This versatile coating can be applied directly to various surfaces, including metal, PVC, concrete, EPDM, cap-sheet, wood, stucco, sheetrock, and more. It adheres effectively and maintains flexibility to prevent cracking
​
Exceptional Properties
SBS-Thirty-Plus offers numerous advantages, including high insulation capacity, resistance to UV, adverse weather, abrasion, and corrosion. It does not require a topcoat and contains no zinc, lead, or chromates. Additionally, it can be used to encapsulate asbestos, reducing the need for tear-off and landfill waste.
ASTM Test Data
-
Passed 500-hour Salt fog test (ASTM B117)
-
Excellent Thermal Conductance (ASTM 518)
-
Excellent Thermal Conductivity (ASTM 518)
-
Hardness: 85 Shore Durometer (ASTM D-2240)
-
Class A Fire Rated (ASTM E108-91A UBC32-7)
-
Tensile Strength: 1393 PSI (ASTM D-638)
-
Water Vapor Transmission: 0.7 perms (ASTM E-96)
-
SRI value: 110 initial, -99/3 years
-
Emittance value: 0.87 initial, 0.98/3 years
-
Reflectance value: 0.87 initial, 0.79/3 years
-
Withstood 500-hour accelerated weathering test (ASTM G-53)
-
Retained flexibility in sub-zero conditions (down to -92°F) (Various ASTM tests)
Features & Benefits:
-
High insulation capacity
-
Application over damp surfaces and underwater
-
Minimal prep work on rusty metal
-
Excellent resistance to UV, adverse weather, abrasion, and corrosion
-
Strong adhesion to substrate
-
Durable wear surface, no topcoat required.
-
Eco-friendly: Contains no zinc, lead, or chromates
-
Suitable for roofs, metal buildings, ducts, concrete walls, basements, and more
Application Methods
SBS-Thirty Plus can be applied using brushes, rollers, or sprayers. Surface preparation is essential, including cleaning and removal of loose rust, mill scale, paint, grease, and other contaminants. The product can be applied to damp surfaces, and for the best results, the surface should be dry.
Mixing
Prior to combining Part A and Part B, both parts should be power-mixed separately for two minutes. Mixing Part, A should result in a cloudy or milky appearance. Combine Part A and Part B in a 4:1 ratio and power-mix for an appropriate duration. Thinning is possible but may require additional coats for desired thickness. Clean equipment promptly with specified solvents.
Safety and Storage
SBS-Thirty-Plus should be used in well-ventilated areas with appropriate safety gear. It has a shelf life of one year when stored properly. Safety, environmental, and disposal information can be found in the Material Safety Data Sheet.
Please note that the suitability of this product for specific applications is the responsibility of the end user, and no specific R-value claims are made by SBS.
